Seamless bend - 22°

long spigot for butt- and electrofusion welding
compliant with EN 12201 & EN 1555

SDR 11
Art. No.	d1 [mm]	e [mm]	d2 [mm]	d3 [mm]	d4 [mm]	di [mm]	D [mm]	D1 [mm]	D2 [mm]	R [mm]	le1 [mm]	le1* [mm]	le2 [mm]	le3 [mm]	L [mm]	L1 [mm]	L2 [mm]	z1 [mm]	z2 [mm]	z3 [mm]	H [mm]	h1 [mm]	h2 [mm]	h6 [mm]	z5 [mm]	s1 [mm]	s2 [mm]	r [mm]	K [mm]	n	ød [mm]	C1 [mm]	C3 [mm]	ND [mm]	hC [mm]	PFA [bar]	SW [mm]	kg/m	Fmax [kn]	kg	Box Quantity	Pallet Quantity
4312001100630000	63	0	0	0	0	0	0	0	0	0	0	100	0	0	0	0	0	150	0	0	0	0	0	0	0	0	0	95	0	0	0	0	0	0	0	0	0	0	0	0,3	0	0

other dimensions, materials and pressure classes on request
Tolerance: α ± 5° | z1 ± 50 mm
* minimum „le1“
