Tee
reduced (non reinforced saddle mounted)
- Material: PP
- long spigot for butt- and electrofusion welding
- saddle mounted, non-reinforced
- other materials, dimensions and pressure classes on request
- tolerance ± 2°
INFO
The maximum allowable operating pressure PFA (20° C water) in due consideration of the pressure reduction factor ƒB can be determined as follows: PFA = PN pipe x ƒB
Tee equal 90°, segment welded, PP, grey
welded from pipe, non-reinforced saddle mounted,
long spigot for butt- and electrofusion welding
pressure reduction factor 0.6,
welds inside debeaded
SDR-class ….., outside diameter d …. / …. mm
(manufacturer: STAR Piping Systems GmbH,Wesel
technical datasheets at www.star.de.com
Tel.: 0281/98414-0 or similar)
